Home  >  Thermostats and IAQ  >  Indoor Air Quality  >  Air Filters and Media  > 0474845 15x20x2 XP-STD2-245

0474845 15x20x2 XP-STD2-245 WAS:5251104925 15X20X2 KP-STD2

Item #: 48416
Manufacturer Item: 0474845
Manufacturer: PARKER/CLARCOR
15" x 20" x 2", 1050 CFM at 500 FPM, Synthetic Media, MERV 8, Pleated, Disposable, Panel Air Filter
48416

Standard Capacity

Automated Process Delivers Consistency and Durability

No Metal, Fully Incinerable

Die Cut Frame with Interlocking Corners for Added Strength

A Seven-Strap Die Cut is Located on the Air Leaving Side of the Key Pleat MERV 8 Providing Additional Strength and Durability to Each Filter

100% Adhesive Application Ensures Filter Strength

Water Repellant Adhesive

Uniformity of Pleats

High Strength and Rigidity, Resulting in Full Depth Loading and Enhanced Dust Holding Capacity

Mechanical Efficiency Produces Increased Efficiency as Media Loads

Made in USA

Air Filters and Media

Type
Pleated, Disposable
Overall Height
20 Inch
Overall Width
15 Inch
Overall Depth
2 Inch
Applicable Standard
UL (Canada and US), UL 900, NAFA, ASHRAE 52.2, ISO
Flow Rate
1050 CFM at 500 FPM
Resistance
0.3 Inch WG (Initial), 1 Inch WG (Final)
Media
Synthetic
Application
Industrial, Commercial
Frame Detail
1-Piece, Heavy Duty, Die Cut, Moisture Resistant B
MER Value
8
Temperature Rating
150 Deg F
Media Area
6 Square Foot
Number of Pleats
10.16 per Foot
