5251421338 20X20X2 KPH-STD2 0002 KEY PLEAT MERV8

Item #: 48346
Manufacturer Item: KPH-STD2-0002_20X20X
Manufacturer: PARKER/CLARCOR
20" x 20" x 2", 1400 CFM at 500 FPM, Synthetic Media, MERV 8, High Capacity, Self-Supported, Pleated, Panel Air Filter
48346

Self-supported media-no metal wire backing

100% synthetic media resists moisture, mold and damage

High strength and rigidity, resulting in full depth loading and enhanced dust holding capacity

Die cut, 1-piece beverage board frame

100% water repellent, high-strength adhesive coats entire interior of frame

Boxed pleat tips provide surface area for adhesion

Pleat Consistency

Synthetic media does not support microbial growth

Fully incinerable, environmentally friendly disposal

Durable and damage resistant construction

Die cut adhesion and design engineered for high strength and support

Uniform pleat spacing maximizes performance

Made in USA

Air Filters and Media

Type
High Capacity, Self-Supported, Pleated, Disposable
Overall Height
20 Inch
Overall Width
20 Inch
Overall Depth
2 Inch
Applicable Standard
UL (Canada and US), UL 900, ASHRAE 52.2
Flow Rate
1400 CFM at 500 FPM
Resistance
0.18 Inch WG (Initial), 1 Inch WG (Final)
Media
100 Percent Synthetic
Application
Commercial, Low and Medium Dust Loading Industrial
Frame Detail
Die-Cut, 1-Piece Heavy Duty Moisture Resistant Bev
MER Value
8
Temperature Rating
150 Deg F
Media Area
12.9 Square Foot
Number of Pleats
16.4 per Foot
