5251123101 20X20X2 KP-STD2 0002 KEY PLEAT MERV8

Item #: 48335
Manufacturer Item: KP-STD2-0002_20X20X2
Manufacturer: PARKER/CLARCOR
20" x 20" x 2", 1400 CFM at 500 FPM, Synthetic Media, MERV 8, Pleated, Disposable, Panel Air Filter
48335

Standard Capacity

Automated Process Delivers Consistency and Durability

No Metal, Fully Incinerable

Die Cut Frame with Interlocking Corners for Added Strength

A Seven-Strap Die Cut is Located on the Air Leaving Side of the Key Pleat MERV 8 Providing Additional Strength and Durability to Each Filter

100% Adhesive Application Ensures Filter Strength

Water Repellant Adhesive

Uniformity of Pleats

High Strength and Rigidity, Resulting in Full Depth Loading and Enhanced Dust Holding Capacity

Mechanical Efficiency Produces Increased Efficiency as Media Loads

Made in USA

Air Filters and Media

Type
Pleated, Disposable
Overall Height
20 Inch
Overall Width
20 Inch
Overall Depth
2 Inch
Applicable Standard
UL (Canada and US), UL 900, NAFA, ASHRAE 52.2, ISO
Flow Rate
1400 CFM at 500 FPM
Resistance
0.3 Inch WG (Initial), 1 Inch WG (Final)
Media
Synthetic
Application
Industrial, Commercial
Frame Detail
1-Piece, Heavy Duty, Die Cut, Moisture Resistant B
MER Value
8
Temperature Rating
150 Deg F
Media Area
8 Square Foot
Number of Pleats
10.16 per Foot
