Home  >  Thermostats and IAQ  >  Indoor Air Quality  >  Air Filters and Media  > 0474710 12x24x1 XP-STD1-110

0474710 12x24x1 XP-STD1-110 5251083881 12X24X1 KP-STD1 2401 KEY PLEAT MERV8

Item #: 48326
Manufacturer Item: 0474710 12X24X1 XP
Manufacturer: PARKER/CLARCOR
12" x 24" x 1", 600 CFM at 300 FPM, Synthetic Media, MERV 8, Standard, Self-Supported, Pleated, Disposable, Panel Air Filter
48326

Self-supported media-no metal wire backing

100% synthetic media resists moisture, mold and damage

High strength and rigidity, resulting in full depth loading and enhanced dust holding capacity

Die cut, 1-piece beverage board frame

100% water repellent, high-strength adhesive coats entire interior of frame

Boxed pleat tips provide surface area for adhesion

Pleat Consistency

Synthetic media does not support microbial growth

Fully incinerable, environmentally friendly disposal

Durable and damage resistant construction

Die cut adhesion and design engineered for high strength and support

Uniform pleat spacing maximizes performance

Made in USA

Air Filters and Media

Type
Standard, Self-Supported, Pleated, Disposable
Overall Height
24 Inch
Overall Width
12 Inch
Overall Depth
1 Inch
Applicable Standard
UL (Canada and US), UL 900, ASHRAE 52.2
Flow Rate
600 CFM at 300 FPM
Resistance
0.15 Inch WG (Initial), 1 Inch WG (Final)
Media
100 Percent Synthetic
Application
Commercial, Low and Medium Dust Loading Industrial
Frame Detail
Die-Cut, 1-Piece Heavy Duty Moisture Resistant Bev
MER Value
8
Temperature Rating
150 Deg F
Media Area
3.4 Square Foot
Number of Pleats
12 per Foot
